🔧 Tucson - Front Brake Pad & Rotor Replacement

This repair replaces the front brake pads and front brake rotors on your Tucson. The pads create the stopping friction, and the rotors are the metal discs the pads clamp onto when you brake.

Difficulty Level: Beginner to Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never work under a vehicle supported by only a jack.
• ⚠️ Use jack stands. Jack stands are fixed supports that hold the vehicle safely after lifting.
• ⚠️ Front brakes can be very hot after driving. Let them cool before touching anything.
• ⚠️ Brake dust is harmful. Do not blow it with compressed air; use brake cleaner instead.
• ⚠️ Brake fluid can damage paint. Wipe spills immediately with a clean rag and water.
• ⚠️ Battery disconnect is not required for this front brake repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 21mm lug nut socket
• 3/8-inch ratchet
• 1/2-inch breaker bar
• 14mm socket
• 17mm socket
• 17mm box-end wrench
• Phillips #3 screwdriver
• Impact screwdriver with Phillips #3 bit
• C-clamp 6-inch
• Brake caliper piston compression tool (specialty)
• Torque wrench 10-150 ft-lbs
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Wire brush
• Brake cleaner spray
• Shop rags
• Bungee cord 18-inch
• Small pry bar 12-inch
• Rubber mallet 16-ounce
• Micrometer or vernier caliper (specialty)
• Nitrile gloves
• Safety glasses
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Front brake hardware kit - Qty: 1
• Brake caliper slide pin grease - Qty: 1
• Brake cleaner - Qty: 2 cans
• DOT 3 or DOT 4 brake fluid - Qty: 1 small bottle

---

📋 Before You Begin

• 🚗 Park your Tucson on level ground and shift the transmission into Park.
• 🧱 Place wheel chocks behind both rear tires. Wheel chocks are blocks that stop the vehicle from rolling.
• 🅿️ Set the parking brake before lifting the front of the vehicle.
• 🧴 Open the hood and locate the brake fluid reservoir. It is the small plastic tank near the driver-side rear of the engine bay.
• 👀 Check the brake fluid level. If it is at the MAX line, remove a small amount with a clean suction tool before compressing the caliper pistons.
• 📌 Your Tucson uses a normal hydraulic front brake caliper. No scan tool or electronic parking brake service mode is needed for the front brakes.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use the 21mm lug nut socket and 1/2-inch breaker bar to loosen each front wheel lug nut about half a turn.
• Do this while the tires are still on the ground so the wheels do not spin.
• Do not remove the nuts yet.

Step 2: Lift and Support the Front of the Tucson

• Use the floor jack rated 3-ton minimum at the front center lifting point or approved front pinch weld area.
• Raise the front of your Tucson high enough for both front wheels to clear the ground.
• Place jack stands rated 3-ton minimum under the approved front support points.
• Gently lower the vehicle onto the jack stands using the floor jack.
• Give the vehicle a light shake by hand. It should feel stable before you continue.

Step 3: Remove the Front Wheels

• Use the 21mm lug nut socket and 3/8-inch ratchet to remove the loosened lug nuts.
• Remove both front wheels and place them flat under the side of the vehicle as an extra safety backup.

Step 4: Inspect the Brake Assembly

• Put on safety glasses, nitrile gloves, and a dust mask.
• Look at the caliper, pads, rotor, and brake hose before taking anything apart.
• The caliper is the clamp-shaped part that squeezes the brake pads against the rotor.
• Spray dusty areas with brake cleaner spray and wipe with shop rags.

Step 5: Remove the Lower Caliper Bolt

• Use a 14mm socket and 3/8-inch ratchet to remove the lower caliper slide bolt.
• If the slide pin spins, hold the pin with a 17mm box-end wrench while loosening the bolt with the 14mm socket.
• A slide pin is a smooth pin that lets the caliper move in and out evenly.

Step 6: Swing the Caliper Up

• Use the small pry bar 12-inch gently between the caliper and old pad if the caliper is tight.
• Swing the caliper upward away from the rotor.
• Support the caliper with the bungee cord 18-inch from the strut spring.
• Do not let the caliper hang by the rubber brake hose.

Step 7: Remove the Old Brake Pads and Hardware

• Pull the old inner and outer brake pads out by hand.
• Use the small pry bar 12-inch if the pads are stuck in the bracket.
• Remove the old metal pad clips from the caliper bracket by hand or with the small pry bar 12-inch.
• The pad clips are thin stainless pieces that help the pads slide quietly and evenly.

Step 8: Remove the Caliper Bracket

• Use the 17mm socket and 1/2-inch breaker bar to remove the two caliper bracket bolts.
• Remove the caliper bracket from the steering knuckle.
• Set the bracket on a clean surface.

Step 9: Remove the Front Rotor

• Use the Phillips #3 screwdriver to remove the rotor retaining screw if equipped.
• If the screw is stuck, use the impact screwdriver with Phillips #3 bit. An impact screwdriver twists when struck and helps loosen stuck screws.
• Pull the rotor straight off the hub.
• If the rotor is rusted on, tap the rotor hat area with the rubber mallet 16-ounce.
• Do not hit the wheel studs with the mallet.

Step 10: Clean the Hub Face

• Use the wire brush to clean rust and dirt from the wheel hub face.
• Spray the hub with brake cleaner spray and wipe it dry with shop rags.
• The hub face must be clean so the new rotor sits flat and does not cause brake vibration.

Step 11: Prepare and Install the New Rotor

• Spray both sides of the new rotor with brake cleaner spray.
• Wipe both sides dry with shop rags.
• Slide the new rotor onto the hub by hand.
• Install the rotor retaining screw with the Phillips #3 screwdriver if equipped.
• Torque to 4-6 Nm (35-53 in-lbs) if a retaining screw is installed.

Step 12: Service the Caliper Bracket

• Use the wire brush to clean the pad contact areas on the caliper bracket.
• Spray the bracket with brake cleaner spray and dry it with shop rags.
• Install the new front brake hardware kit clips by hand.
• Apply a thin film of brake caliper slide pin grease only where the pads touch the clips.
• Do not get grease on the rotor or pad friction surface.

Step 13: Check and Grease the Slide Pins

• Pull each slide pin out of the caliper bracket by hand.
• Wipe old grease off with shop rags.
• Inspect the rubber boots for tears.
• Apply fresh brake caliper slide pin grease to the pins.
• Push the slide pins back into the bracket by hand until they move smoothly.

Step 14: Reinstall the Caliper Bracket

• Place the caliper bracket over the new rotor.
• Start both bracket bolts by hand first to avoid cross-threading.
• Use the 17mm socket and torque wrench 10-150 ft-lbs to tighten the bracket bolts.
• Torque to 88-98 Nm (65-72 ft-lbs).

Step 15: Install the New Brake Pads

• Slide the new inner and outer brake pads into the caliper bracket by hand.
• Make sure the friction material faces the rotor.
• The pads should move slightly by hand. If they are jammed, remove them and recheck the clips and bracket cleaning.
• Pads should slide, not rattle.

Step 16: Compress the Caliper Piston

• Check the brake fluid reservoir under the hood before compressing the piston.
• Place one old brake pad against the caliper piston.
• Use the C-clamp 6-inch or brake caliper piston compression tool to slowly push the piston fully into the caliper.
• The piston is the round metal piece inside the caliper that pushes the brake pad.
• Compress slowly so brake fluid does not overflow from the reservoir.

Step 17: Reinstall the Caliper

• Remove the bungee cord 18-inch and swing the caliper down over the new pads.
• Start the lower caliper slide bolt by hand.
• Use the 14mm socket and torque wrench 10-150 ft-lbs to tighten the caliper slide bolt.
• If the slide pin spins, hold it with the 17mm box-end wrench.
• Torque to 22-32 Nm (16-24 ft-lbs).

Step 18: Repeat on the Other Front Side

• Repeat Steps 4 through 17 on the opposite front wheel.
• Always replace front pads and rotors in pairs so braking stays even.

Step 19: Reinstall the Wheels

• Install each wheel by hand.
• Thread all lug nuts by hand first.
• Use the 21mm lug nut socket and 3/8-inch ratchet to snug the lug nuts in a star pattern.
• A star pattern means tightening across the wheel, not around in a circle.

Step 20: Lower and Torque the Wheels

• Use the floor jack rated 3-ton minimum to lift the front slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower your Tucson until the tires touch the ground.
• Use the 21mm lug nut socket and torque wrench 10-150 ft-lbs to tighten lug nuts in a star pattern.
• Torque to 88-108 Nm (65-80 ft-lbs).

Step 21: Pump the Brake Pedal

• Sit in the driver seat and press the brake pedal slowly several times.
• The pedal may go low at first. Keep pumping until it feels firm.
• This moves the caliper pistons back against the new brake pads.
• Do not drive until the pedal feels firm.

Step 22: Check Brake Fluid Level

• Open the hood and check the brake fluid reservoir.
• Add DOT 3 or DOT 4 brake fluid only if the level is below the MIN mark.
• Use shop rags to wipe any spills right away.
• Install the reservoir cap securely.

---

✅ After Repair

• ✅ Start your Tucson and press the brake pedal again. It should feel firm and steady.
• ✅ With the vehicle still parked, shift to Drive and Reverse briefly while holding the brake to confirm normal stopping feel.
• ✅ Perform a slow test drive in a safe area. Start at 5-10 mph and make gentle stops.
• ✅ Bed in the new pads if the pad manufacturer recommends it. Bedding-in means making controlled stops to transfer an even layer of pad material to the rotor.
• ✅ For a simple bedding method, make 8-10 moderate stops from about 30 mph to 5 mph, allowing a short cooling period between stops.
• ✅ Avoid hard braking for the first 200 miles unless it is an emergency.
• ✅ Recheck lug nut torque after 25-50 miles using the 21mm lug nut socket and torque wrench 10-150 ft-lbs.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 USD equivalent (parts + labor)

DIY Cost: $120-$280 USD equivalent (parts only)

You Save: $230-$370 USD equivalent by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
